halogênio 4" livre de 3-100mm luva trançada expansível do ANIMAL DE ESTIMAÇÃO

halogênio 4" livre de 3-100mm luva trançada expansível do ANIMAL DE ESTIMAÇÃO

  • halogênio 4" livre de 3-100mm luva trançada expansível do ANIMAL DE ESTIMAÇÃO
  • halogênio 4" livre de 3-100mm luva trançada expansível do ANIMAL DE ESTIMAÇÃO
halogênio 4" livre de 3-100mm luva trançada expansível do ANIMAL DE ESTIMAÇÃO
Detalhes do produto:
Lugar de origem: Shenzhen de China
Marca: Huiyunhai
Certificação: UL, RoHS
Número do modelo: HYH
Condições de Pagamento e Envio:
Quantidade de ordem mínima: Negociável
Preço: Negotiable
Detalhes da embalagem: caixa padrão da exportação
Termos de pagamento: T/T, Western Union
Habilidade da fonte: 3 milhão medidores pelo mês
Contato
Descrição de produto detalhada
Nome do produto: VW - 1 Sleeving trançado ANIMAL DE ESTIMAÇÃO Característica: Chama resistente
Cor: Colorido Largura: Opcional
Uso: proteção do cabo Certificados: UL, RoHS
Realçar:

Luva trançada do ANIMAL DE ESTIMAÇÃO livre do halogênio

,

4" Sleeving trançado expansível do cabo

Durable PET Expandable Braided Sleeve Cable For Wire Harness



Description for Durable PET Expandable Braided Sleeve



Expandable braided sleeves is ideal for a limitless number of electronic, automotive, marine and industrial wire management and bundling applications. Examples include engine compartment dress up, home theater wire management, customizing computer case wiring, office wire management, automotive harnesses, scuba hose protection, and many more. Threads of different colors and textures could be braided into different patterns. Each of our products is tailored to the client's business and needs.

With excellent flexibility, flame resistance, wear resistance and heat insulation.

Strong corrosion resistance and abrasion resistance.

Excellent softness, easy to bend.

Durable in use.

Can be used for wire and cable protection, pipe and hose, indoor wiring etc.

Cable sleeve offers durable abrasion resistance in a wide range of industrial applications.

The open weave construction allows an easy installation on a bundle of hoses and cables, even if some with bulky or large connectors.

Totally expanded the sleeving can reach at least one point five times than the initial dimension.



Technical data of  Durable PET Expandable Braided Sleeve


1. Size: 3~ 100 mm
2. Operating range: -103F to 257F (-75C to 125C) temperature range
3. Melt Point:446F (230C)
4. Expands up to 150%
5. Available up to 4" in diameter
6. Colors:black, grey, white, red, green, blue, yellow, purple, pink, orange etc.
7. Certificate: SGS, UL, RoHS approved
8. Halogen free



Dimension Data of Durable PET Expandable Braided Sleeve







Nominal
Size
Product
Part #
Expansion Range Spool Put-Ups
    Min. Max. Bulk Shop
1/16"
1/8"
1/4"
3/8"
1/2"
5/8"
3/4"
1"
1 1/4"
1 1/2"
1 3/4"
2"
2 1/2"
3"
CBS0.06
CBS0.13
CBS0.25
CBS0.38
CBS0.50
CBS0.63
CBS0.75
CBS1.00
CBS1.25
CBS1.50
CBS1.75
CBS2.00
CBS2.50
CBS3.00
3/64"
3/32"
1/8"
3/16"
1/4"
3/8"
1/2"
5/8"
3/4"
1"
1 1/4"
1 1/2"
1 3/4"
2 1/2"
3/32"
1/4"
7/16"
1/2"
3/4"
1"
1 1/4"
1 5/8"
1 3/4"
2 1/8"
2 3/4"
3 1/2"
3 5/8"
4 3/4"
1,000'
1,000'
1,000'
500'
500'
500'
250'
250'
250'
200'
200'
200'
200'
100'
250'
225'
200'
125'
100'
100'
75'
65'
50'
40'
30'
50'
50'
50'
3/4" PTL0.75BK 1/2" 1 1/4" 250' 75'





Detailed Description of Durable PET Expandable Braided Sleeve





Model Number  PET Expandable Braided Sleeving
Certification  UL ROHS
Place of Origin  Shenzhen of China
MOQ  1000 meters
Price  Deliberate
Payment Terms  L/C, T/T, Western Union
Supply Ability  50000meters /day
Delivery Time  5-7days
Packaging Details  Roll
Material  PET
Melting Point  230C+5
Temperature Range  -50C ~+150C
Fire Resistance Rating  VW-1
Certificate  SGS, Reach And ROHS
Colors  Black/white/clrear/blue/pink/yellow/red/yellow
